| Insertion loss |
0.8dB max. |
| Temperature dependence |
0.3dB max. |
| Flatness |
0.1dB max. |
| PDL |
0.1dB max. |
| PMD |
0.1 ps max. |
| Back-reflection |
-50dB max. |
| Optical power |
300mW max. |
| Switching time |
5ms max. |
| Repeatability |
0.1dB max. |
| Wear-out |
1 × 108 cycles min. |
| Fiber type |
9/125 Corning SMF-28 |
| Fiber jacket |
250micron,200kpsi bare fiber |
| Operating temperatuere |
-5℃〜+75℃ |
| Storage temperature |
-40℃〜+85℃ |
|
| Latching type |
Non-latching |
| Control type |
Voltage control |
| TTL or I2C control |
| Voltage Control type |
45dB off stete drive voltage |
Tranparent type |
4.5 - 5 VDC |
| opaque type |
-0.2 - +0.2VDC |
| Volltage damage threshold |
10 VDC max. |
| Resistance |
100 Kohms min. |
| Capacitance |
2 pf typ. |
| Power consumption |
20μW max. |
| TTL or I2C Control Type |
Vcc voltage |
4.8 - 5VDC |
| Vcc power consumption |
150mW max. |
|
